Mini 1.5v 9v 12v Dc Motor 14000 Rpm 20000rpm for Micro Fan Can Match Counter Weight

Promotion

Product Description

Model		Rated Voltage (V)		No-Load		Rated				Stall
PMDC MOTOR Technical Data
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
FF-030PA	11155	2.0~4.0	3VDC	7200	45	5500	170	0.49/5	0.28	590	2.06/21
FF-030PA	1592	2.0~4.0	3.5VDC	14300	90	12500	300	0.49/5	0.64	2000	3.92/40
FF-030PK	05440	3.5~12.0	12VDC	11000	20	7800	65	0.49/5	0.4	180	1.67/17

Click on the tilt font to know more parameters!

Application

Our Company

Established in 2005, the enterprise is a high-tech manufacturer integrating the research, development, production and sales of various kinds of micro DC motor, geared motor, planetary geared motor, shade pole geared motor and special gearbox motor. Products are widely used in automobiles, communications equipment, smart home, medical equipment, intelligent security, household appliances, western kitchen equipment, machinery and electronics and other high-end transmission structures, products are exported to more than 50 countries and regions at home and abroad.

Production Process

Certifications

The enterprise has introduced dozens of advanced production equipment and testing instruments from Germany, Japan, Switzerland and other countries to strictly control the quality of each motor.

FAQ

Q1 Are you a trading company or manufacturer?

We are a factory. We specialize in micro DC motors and DC gear motors for over 14 years.

Q2 What is the payment term for new customers?

We can process Assurance Orders online, which allows payment via MasterCard, Visa, etc. Customers can also pay using PayPal or T/T.

Q3 Can you customize the motor according to our requirements?

Yes, we can customize a suitable motor based on our customers' specific requirements.

Q4 Do you have certificates for the motors?

Yes, we have CE, FCC, ISO, and other relevant certificates. If you have other specific certification requirements, we can apply for them.

Q5 How is your Quality Control?

We have professional checking staff on every production line process. After finishing the whole motor, we use testing equipment such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise testers to ensure quality.

Q6 Can we request samples for testing?

Yes, samples can be provided for evaluation and performance testing to ensure they meet your performance specifications before placing bulk orders.
