SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

1 / 4

SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Refer to the italicized parameters below to learn more options.

Application Range & Features

Application collage of micro PMDC motors

SRC-370SH-4730 Dimensions and Specifications

Frequently Asked Questions

What is the operating voltage range of the SRC-370SH-4730 PMDC Motor?

The motor has an operating voltage range of 3.0V to 5.0V, with a nominal rated voltage of 4.5V DC.

What are the no-load speed and current specifications for this motor?

Under no-load conditions, the motor delivers a high-speed performance of 17,500 RPM with a current draw of 550 mA.

What is the rated power output of the SRC-370SH-4730?

It features a rated power output of 11.51W, running at a rated speed of 15,199 RPM and a current of 3.63A (3630 mA).

How much torque does this micro motor generate?

The motor provides a rated torque of 7.2 mN.m (73.4 gf.cm) and can reach a stall torque up to 55 mN.m (561 gf.cm).

What are the typical applications for these micro PMDC motors?

These motors are designed for high efficiency and versatility. They are extensively utilized in home automation, smart security systems, automotive equipment, electronic locks, personal care devices, and high-performance toys.
